jl254a Aruba 2930F 48G 4SFP+ Switch

jl254a



The Aruba 2930F Switch Series is designed for customer creating digital workplaces optimized for mobile users. These Layer 3 access switches are easy to deploy and manage with advanced security and network management tools like Aruba ClearPass Policy Manager, Aruba AirWave and cloud-based Aruba Central. Virtual Switching Framework (VSF) provides stacking scale and simplicity for enterprise edge, SMB and branch offices. The 2930F delivers performance and value with support for RIP routing, Access OSPF, 10GbE uplinks, up to 740W PoE+, robust QoS, and requires no software licensing.

The HPE Aruba Networking 2930F Switch Series is designed for customers creating smart digital workplaces that are optimized for mobile users with an integrated wired and wireless approach. These convenient Layer 3 network switches include built-in uplinks and PoE power and are simple to deploy and manage with advanced security and network management tools like HPE Aruba Networking ClearPass Policy Manager, Aruba AirWave and cloud-based HPE Aruba Networking Central.
A powerful HPE Aruba Networking Pro Vision ASIC delivers performance, robust feature support and value with programmability for the latest applications. Stacking with Virtual Switching Framework (VSF) provides simplicity and scalability. The 2930F supports built-in 1GbE or 10GbE uplinks, PoE+, Access OSPF routing, Dynamic Segmentation, robust QoS, RIP routing, and IPv6 with no software licensing required. The HPE Aruba Networking 2930F Switch Series provides a convenient and cost-effective access switch solution that can be quickly set up with Zero Touch Provisioning. The robust basic Layer 3 feature set includes a limited lifetime warranty.

Key Features

• HPE Aruba Networking Layer 3 switch series with VSF stacking, static, RIP and Access OSPF Routing, dynamic segmentation, ACLs, and robust QoS
• Supports cloud and on-premises management. And advanced policy management using HPE Aruba Networking Clear Pass
• Convenient built-in 1GbE or 10GbE uplinks and up to 740 W PoE+
• Software-defined ready with REST APIs and Open Flow support
• Simple deployment with Zero Touch Provisioning

Differentiator

Popular Aruba 52-port Gig + 10G access switch.

This model has 48x 10/100/1000 ports and 4x 10G / 1G SFP+ transceiver slots for uplink connectivity.

Power consumption46.6 W (maximum)

Heat dissipation157.2 BTU/hr (165.8 kJ/hr)

Input voltage100 – 127 / 200 – 240 VAC, rated

Ports(48) RJ-45 autosensing 10/100/1000 ports

(4) SFP+ 1/10GbE ports

PHY-less

Latency 1000 Mb Latency: < 3.8 µs

10 Gbps Latency: < 1.6 µs

Switching capacity176 Gbps

Through put up to 112 Mpps

Memory and processor Dual Core ARM Cortex A9 @ 1016 MHz

1 GB DDR3 SDRAM

Packet buffer size: 12.38 MB 4.5MB Ingress/7.875MB Egress

4 GB eMMC

PoE capability740 W PoE+ maximum, depending on model

Management features

Aruba Air Wave

Central Network Management

IMC – Intelligent Management Center

Command-line interface

Web browser

Configuration menu

SNMP manager

Telnet

RMON1

FTP

Out-of-band management (serial RS-232C or micro USB)

Warranty Limited Lifetime Warranty: See www.hpe.com/networking/warrantysummary for warranty and support information included with your product purchase.

Weight3.1 kg (6.83 lb)

Dimensions4.39 x 44.25 x 24.63 cm (1.73 x 17.42 x 9.7 in)
